Katalogtext
EDELSTAHL
RUNDROHR EDELSTAHL 1.4301 GESCHW.
EN10296-2/EN10088
mm mm Länge kg/mtr GTIN mm mm Länge kg/mtr GTIN
mtr mtr
10,0 1,0 6 0,225 4062768178465 48,3 2,5 6 2,975 4062768179257
16,0 1,0 6 0,367 4062768180673 48,3 3,0 6 3,403 4062768180062
20,0 1,0 6 0,476 4062768178694 50,0 2,0 6 2,404 4062768179301
20,0 2,0 6 0,901 4062768178212 50,0 3,0 6 3,530 4062768180710
21,3 2,0 6 0,967 4062768178229 54,0 2,0 6 2,604 4062768179387
21,3 2,5 6 1,177 4062768178724 60,3 2,0 6 2,920 4062768178304
22,0 2,0 6 1,002 4062768178755 60,3 2,5 6 3,618 4062768179455
25,0 1,5 6 0,883 4062768178793 60,3 3,0 6 4,300 4062768179479
25,0 2,0 6 1,152 4062768178236 70,0 2,0 6 3,405 4062768179561
26,9 2,0 6 1,247 4062768178243 70,0 3,0 6 5,030 4062768179585
26,9 2,5 6 1,527 4062768178823 76,1 2,0 6 3,711 4062768179608
28,0 1,0 6 0,676 4062768178830 76,1 3,0 6 5,490 4062768179639
28,0 1,5 6 0,995 4062768178847 84,0 2,0 6 4,107 4062768179677
30,0 2,0 6 1,402 4062768178250 88,9 2,0 6 4,352 4062768179707
32,0 2,0 6 1,502 4062768178922 88,9 3,0 6 6,453 4062768179745
33,7 2,0 6 1,588 4062768178267 88,9 4,0 6 8,504 4062768179769
33,7 2,5 6 2,025 4062768178953 101,6 2,0 6 4,988 4062768179783
33,7 3,0 6 2,306 4062768178960 101,6 3,0 6 7,407 4062768179790
40,0 2,0 6 1,903 4062768178274 101,6 4,0 6 9,776 4062768180659
40,0 3,0 6 2,779 4062768179141 114,3 2,0 6 5,624 4062768179844
42,4 2,0 6 2,023 4062768178281 114,3 3,0 6 8,361 4062768180185
42,4 2,5 6 2,591 4062768179165
42,4 3,0 6 3,141 4062768179172
48,3 2,0 6 2,319 4062768178298
RUNDROHR EDELSTAHL 1.4301 GESCHW. GESCHL. K240
EN10296-2/EN10088
mm mm Länge kg/mtr GTIN mm mm Länge kg/mtr GTIN
mtr mtr
10,0 1,5 6 0,319 4062768180116 42,4 2,0 6 2,023 4062768178328
12,0 1,5 6 0,394 4062768180123 42,4 2,5 6 2,498 4062768180321
14,0 1,5 6 0,470 4062768180130 42,4 3,0 6 2,960 4062768180277
15,0 1,5 6 0,509 4062768180178 48,3 2,0 6 2,319 4062768180505
16,0 1,0 6 0,376 4062768178595 48,3 2,5 6 2,867 4062768180253
16,0 1,5 6 0,545 4062768180192 48,3 3,0 6 3,403 4062768180284
16,0 2,0 6 0,701 4062768180147 48,3 4,0 6 4,440 4062768180758
17,2 2,0 6 0,761 4062768180154 50,0 2,0 6 2,404 4062768178403
18,0 1,5 6 0,620 4062768180369 54,0 2,0 6 2,604 4062768178410
20,0 1,5 6 0,695 4062768180291 60,3 2,0 6 2,920 4062768178427
20,0 2,0 6 0,901 4062768178342 60,3 3,0 6 4,304 4062768180420
21,3 2,0 6 0,967 4062768178359 70,0 2,0 6 3,405 4062768180642
22,0 2,0 6 1,002 4062768180703 76,1 2,0 6 3,711 4062768180161
25,0 1,5 6 0,883 4062768180727 76,1 3,0 6 5,490 4062768180437
25,0 2,0 6 1,152 4062768178366 80,0 2,0 6 3,906 4062768180468
26,9 2,0 6 1,247 4062768178373 80,0 3,0 6 5,784 4062768180772
26,9 2,5 6 1,527 4062768180635 88,9 2,0 6 4,352 4062768180307
30,0 2,0 6 1,402 4062768178380 88,9 3,0 6 6,453 4062768180444
33,7 2,0 6 1,588 4062768178311 88,9 4,0 6 8,504 4062768180680
33,7 2,5 6 1,953 4062768180079 101,6 2,0 6 4,988 4062768180093
33,7 3,0 6 2,306 4062768180260 101,6 3,0 6 7,407 4062768180451
35,0 2,0 6 1,653 4062768180406 101,6 4,0 6 9,776 4062768180666
38,0 2,0 6 1,803 4062768180390 114,3 2,0 6 5,624 4062768180314
40,0 2,0 6 1,903 4062768178397 114,3 3,0 6 8,361 4062768180628
Wir erweitern ständig unser Lagerprogramm, nicht aufgeführte Abmessungen sind auf Anfrage lieferbar.
