Katalogtext
ALUMINIUM
FLACH ALMGSI0.5 F22 AW6060 GEPRESST
EN755-5/EN573-3
mm mm Länge kg/mtr GTIN mm mm Länge kg/mtr GTIN
mtr mtr
15 3 6 0,125 4062768146877 50 6 6 0,810 4062768147577
15 5 6 0,202 4062768146891 50 8 6 1,080 4062768147584
15 6 6 0,245 4062768146907 50 10 6 1,350 4062768147591
15 8 6 0,324 4062768146914 50 12 6 1,620 4062768147607
15 10 6 0,405 4062768146921 50 15 6 2,030 4062768147614
20 2 6 0,110 4062768146938 50 20 6 2,700 4062768147621
20 3 6 0,165 4062768146945 50 30 6 4,050 4062768147645
20 4 6 0,220 4062768146952 60 2 6 0,325 4062768147690
20 5 6 0,270 4062768146969 60 3 6 0,486 4062768147706
20 6 6 0,325 4062768146976 60 4 6 0,650 4062768147713
20 8 6 0,435 4062768146983 60 5 6 0,810 4062768147720
20 10 6 0,540 4062768146990 60 6 6 0,972 4062768147737
20 12 6 0,648 4062768147003 60 8 6 1,300 4062768147744
20 15 6 0,810 4062768147010 60 10 6 1,620 4062768147751
25 3 6 0,203 4062768147034 60 12 6 1,940 4062768147768
25 4 6 0,270 4062768147041 60 15 6 2,430 4062768147775
25 5 6 0,340 4062768147058 60 20 6 3,240 4062768147782
25 6 6 0,405 4062768147065 70 5 6 0,945 4062768147867
25 8 6 0,540 4062768147072 70 10 6 1,890 4062768147898
25 10 6 0,675 4062768147089 80 2 6 0,440 4062768147980
25 12 6 0,840 4062768147096 80 3 6 0,650 4062768147997
25 15 6 1,015 4062768147102 80 4 6 0,860 4062768148000
25 20 6 1,350 4062768147119 80 5 6 1,080 4062768148017
30 2 6 0,165 4062768147126 80 6 6 1,300 4062768148024
30 3 6 0,245 4062768147133 80 8 6 1,730 4062768148031
30 4 6 0,324 4062768147140 80 10 6 2,160 4062768148048
30 5 6 0,405 4062768147157 80 12 6 2,592 4062768148055
30 6 6 0,490 4062768147164 80 15 6 3,240 4062768148062
30 8 6 0,650 4062768147171 80 20 6 4,320 4062768148079
30 10 6 0,810 4062768147188 90 10 6 2,430 4062768148178
30 12 6 0,975 4062768147195 100 3 6 0,810 4062768148215
30 15 6 1,220 4062768147201 100 4 6 1,100 4062768148222
30 20 6 1,620 4062768147218 100 5 6 1,350 4062768148239
40 2 6 0,220 4062768147348 100 6 6 1,620 4062768148246
40 3 6 0,324 4062768147355 100 8 6 2,160 4062768148253
40 4 6 0,435 4062768147362 100 10 6 2,700 4062768148260
40 5 6 0,540 4062768147379 100 15 6 4,050 4062768148284
40 6 6 0,648 4062768147386 100 20 6 5,600 4062768148291
40 8 6 0,864 4062768147393 120 5 6 1,620 4062768148345
40 10 6 1,080 4062768147409 120 6 6 1,944 4062768148352
40 12 6 1,300 4062768147416 120 8 6 2,600 4062768148369
40 15 6 1,620 4062768147423 120 10 6 3,240 4062768148376
40 20 6 2,160 4062768147430 120 15 6 4,860 4062768148390
40 25 6 2,700 4062768147447 120 20 6 6,480 4062768148406
40 30 6 3,240 4062768147454 150 8 6 3,240 4062768148475
50 2 6 0,270 4062768147539 150 10 6 4,050 4062768148482
50 3 6 0,405 4062768147546 150 15 6 6,075 4062768148499
50 4 6 0,540 4062768147553 200 10 6 5,400 4062768148550
50 5 6 0,675 4062768147560 250 10 6 6,750 4062768148581
Wir erweitern ständig unser Lagerprogramm, nicht aufgeführte Abmessungen sind auf Anfrage lieferbar.
111
