Katalogtext
STABSTAHL
FLACHSTAHL S235JR
EN10058/EN10025
mm mm Länge kg/mtr GTIN mm mm Länge kg/mtr GTIN
mtr mtr
70 30 6 16,500 4062768006157 110 10 6 8,640 4062768006683
70 35 6 19,200 4062768006164 110 12 6 10,400 4062768006690
70 40 6 22,000 4062768006171 110 15 6 13,000 4062768006706
70 50 6 27,500 4062768006188 110 20 6 17,300 4062768006713
75 5 6 4062768006195 110 25 6 21,600 4062768006720
75 6 6 2,940 4062768006201 110 30 6 25,910 4062768006737
75 8 6 3,530 4062768006218 110 40 6 34,500 4062768006744
75 10 6 4,710 4062768006225 110 50 6 43,200 4062768006751
75 12 6 5,890 4062768006232 110 60 6 51,800 4062768007215
75 15 6 7,070 4062768006249 120 8 6 4062768006768
75 20 6 8,830 4062768006256 120 10 6 7,540 4062768006775
75 25 6 11,800 4062768006263 120 12 6 9,420 4062768006782
80 5 6 14,700 4062768006287 120 15 6 11,300 4062768006799
80 6 6 3,140 4062768006294 120 20 6 14,100 4062768006805
80 8 6 3,770 4062768006300 120 25 6 18,800 4062768006812
80 10 6 5,020 4062768006317 120 30 6 23,600 4062768006829
80 12 6 6,280 4062768006324 120 40 6 28,300 4062768006836
80 15 6 7,540 4062768006331 120 50 6 37,700 4062768006843
80 20 6 9,420 4062768006348 120 60 6 47,100 4062768006850
80 25 6 12,600 4062768006355 130 8 6 56,500 4062768006867
80 30 6 15,700 4062768006362 130 10 6 8,160 4062768006874
80 35 6 18,800 4062768006379 130 12 6 10,200 4062768006881
80 40 6 22,000 4062768006386 130 15 6 12,200 4062768006898
80 50 6 25,120 4062768006393 130 20 6 15,300 4062768006904
80 60 6 31,400 4062768006409 130 25 6 20,400 4062768006911
90 5 6 37,700 4062768006416 130 30 6 25,500 4062768006928
90 6 6 3,530 4062768006423 130 40 6 30,600 4062768006935
90 8 6 4,240 4062768006430 130 50 6 40,800 4062768006942
90 10 6 5,650 4062768006447 130 60 6 51,000 4062768007246
90 12 6 7,070 4062768006454 140 8 6 61,250 4062768006959
90 15 6 8,480 4062768006461 140 10 6 8,790 4062768006966
90 20 6 10,600 4062768006478 140 12 6 11,000 4062768006973
90 25 6 14,100 4062768006485 140 15 6 13,200 4062768006980
90 30 6 17,700 4062768006492 140 20 6 16,500 4062768006997
90 40 6 21,200 4062768006515 140 25 6 22,000 4062768007000
90 50 6 28,300 4062768006522 140 30 6 27,500 4062768007017
90 60 6 35,300 4062768006539 140 40 6 33,000 4062768007024
100 5 6 42,400 4062768006546 140 50 6 44,000 4062768007031
100 6 6 3,930 4062768006553 140 60 6 55,000 4062768007239
100 8 6 4,710 4062768006560 150 5 6 65,950 4062768015012
100 10 6 6,280 4062768006577 150 8 6 5,888 4062768007048
100 12 6 7,850 4062768006584 150 10 6 9,420 4062768007055
100 15 6 9,420 4062768006591 150 12 6 11,800 4062768007062
100 20 6 11,800 4062768006607 150 15 6 14,100 4062768007079
100 25 6 15,700 4062768006614 150 20 6 17,660 4062768007086
100 30 6 19,600 4062768006621 150 25 6 23,600 4062768007093
100 35 6 23,600 4062768006638 150 30 6 29,400 4062768007109
100 40 6 27,500 4062768006645 150 40 6 35,300 4062768007130
100 50 6 31,400 4062768006652 150 50 6 47,100 4062768007116
100 60 6 39,300 4062768006669 150 60 6 58,900 4062768007123
110 8 6 47,100 4062768006676 70,700
6,910
Wir erweitern ständig unser Lagerprogramm, nicht aufgeführte Abmessungen sind auf Anfrage lieferbar.
