Katalogtext
BLANK- UND EDELBAUSTAHL
BLANKSTAHL S235JRC+C H11 FLACH
EN10277/EN10278/EN10025
mm mm Länge kg/mtr GTIN mm mm Länge kg/mtr GTIN
mtr mtr
54 3 0,157 4062768102590 22 3 3 0,518 4062768103788
64 3 0,189 4062768102637 22 4 3 0,691 4062768103795
83 3 0,189 4062768102729 22 5 3 0,860 4062768103801
84 3 0,251 4062768102736 22 6 3 1,040 4062768103818
85 3 0,315 4062768102743 22 8 3 1,380 4062768103832
86 3 0,375 4062768102750 22 10 3 1,730 4062768103849
10 2 3 0,157 4062768196377 25 4 3 0,785 4062768110762
10 3 3 0,236 4062768102866 25 5 3 0,980 4062768104082
10 4 3 0,314 4062768102873 25 6 3 1,180 4062768104099
10 5 3 0,393 4062768102880 25 8 3 1,570 4062768104112
10 6 3 0,472 4062768102897 25 10 3 1,960 4062768104129
10 8 3 0,630 4062768102910 25 10 6 1,960 4062768198562
12 3 3 0,283 4062768192133 25 12 3 2,360 4062768104136
12 4 3 0,377 4062768103030 25 14 3 2,750 4062768104150
12 5 3 0,471 4062768103047 25 15 3 2,940 4062768104167
12 6 3 0,570 4062768103054 25 15 6 2,940 4062768110694
12 8 3 0,754 4062768103078 25 16 3 3,140 4062768104174
12 10 3 0,940 4062768103085 25 18 3 3,530 4062768104181
14 3 3 0,330 4062768103191 25 20 3 3,930 4062768104198
14 4 3 0,440 4062768103207 28 5 3 1,100 4062768104365
14 5 3 0,550 4062768103214 28 6 3 1,320 4062768104372
14 6 3 0,660 4062768103221 28 10 3 2,200 4062768104402
14 8 3 0,880 4062768103245 28 12 3 2,640 4062768104419
15 2 3 0,230 4062768103276 30 3 3 0,707 4062768104501
15 3 3 0,353 4062768103290 30 4 3 0,942 4062768104518
15 4 3 0,471 4062768103306 30 5 3 1,180 4062768104525
15 5 3 0,589 4062768103313 30 6 3 1,410 4062768104532
15 6 3 0,707 4062768103320 30 6 6 1,410 4062768110847
15 7 3 0,819 4062768103337 30 8 3 1,880 4062768104556
15 8 3 0,942 4062768103344 30 8 6 1,880 4062768110915
15 8 6 0,942 4062768146815 30 10 3 2,360 4062768104563
15 10 3 1,180 4062768103351 30 10 6 2,360 4062768110861
15 12 3 1,415 4062768103368 30 12 3 2,830 4062768104570
16 2 3 0,250 4062768103382 30 12 6 2,830 4062768110366
16 4 3 0,502 4062768110496 30 14 3 3,290 4062768104594
16 5 3 0,630 4062768103429 30 15 3 3,530 4062768104600
16 6 3 0,750 4062768103436 30 15 6 3,530 4062768110250
16 8 3 1,010 4062768103450 30 16 3 3,770 4062768104617
16 10 3 1,260 4062768103467 30 20 3 4,710 4062768104631
16 12 3 1,505 4062768103474 30 20 6 4,710 4062768109148
18 3 3 0,425 4062768103511 30 25 3 5,890 4062768104655
18 4 3 0,565 4062768103528 30 25 6 5,890 4062768110960
18 5 3 0,710 4062768103535 32 5 3 1,260 4062768104709
18 6 3 0,850 4062768103542 32 8 3 2,010 4062768104730
18 8 3 1,130 4062768103559 32 10 3 2,510 4062768104747
18 10 3 1,410 4062768103566 35 4 3 1,099 4062768104860
18 12 3 1,700 4062768103573 35 5 3 1,370 4062768104877
20 2 3 0,314 4062768193116 35 6 3 1,650 4062768104884
20 3 3 0,471 4062768110595 35 6 6 1,650 4062768193123
20 4 3 0,628 4062768110601 35 8 3 2,200 4062768104907
20 5 3 0,790 4062768110410 35 10 3 2,750 4062768104914
20 6 3 0,940 4062768103672 35 10 6 2,750 4062768109698
20 6 6 0,940 4062768191099 35 12 3 3,300 4062768104921
20 8 3 1,260 4062768103696 35 15 3 4,120 4062768104945
20 10 3 1,570 4062768103702 35 16 3 4,400 4062768104952
20 10 6 1,570 4062768196889 35 18 3 4,950 4062768104969
20 12 3 1,880 4062768103719 35 20 3 5,500 4062768104976
20 15 3 2,360 4062768103733 35 25 3 6,870 4062768104983
20 15 6 2,360 4062768110373 35 25 6 6,870 4062768104990
20 16 3 2,515 4062768103740 35 30 3 8,240 4062768105003
Wir erweitern ständig unser Lagerprogramm, nicht aufgeführte Abmessungen sind auf Anfrage lieferbar.
80
